HSD-212LA
The HSD-212LA active line array series has a compact design structure with great dynamic capacity. the suspension system are made of aluminum alloy material, which is fast and safe to install. High-quality speaker unit configuration, professional linear horn, beautiful sound quality, accurate projection.
SPECIFICATION
Model | HSD-208LA | HSD-210LA | HSD-212LA |
Picture |  | ||
RMS Power | 600W | 800W | 800W |
Peak Power | 1600W | 2000W | 2000W |
Components | LF 2x8”/ 170 magnet 75mm VC B&C HF Neo 2x1.75” | LF2x10”/170magnet 75mm VC B&C HF Neo 2x1.75” | LF2x12”/170magnet 75mm VC B&C HF Neo 2x1.75” |
Normal Impedance | 8 Ohms | 8 Ohms | 4 Ohms |
Frequency Response | 60Hz-18KHz | ||
Sensitivity | 104dB | 109dB | 112dB |
Maximum SPL | 135dB | 139dB | 145dB |
Nominal Dispersion | H100º x V10º | ||
Cabinet Material | 18mm MDF | 18mm plywood | |
Output Connectors | 2 x NL4 Speakon | ||
Surface Finished | spray painting+ metal grille | ||
Dimensions (WHD) | 255x700x415mm | 892x309x463mm | |
Package | 465 x735x320mm | 770x450x355mm | 930x415x540mm |
N.W. | 22.3kg | 39.35kg | 45kg |
G.W. | 24.25kg | 42.25kg | 50kg |
Use | for stage, Karaoke, Party, Disco, indoor dancing,promotion, performance,yoga,class ,meeting,or any other outdoor activities. | ||
