SPE-4000
SPE-4000 power amplifier by the unremitting efforts of R & D engineers, the depth of raw materials carefully screened, carefully compared, and then after rigorous testing of aging, to achieve high damping coefficient, ultra-low distortion, high signal to noise ratio, with sensitive overheating management System and safety Perfect protection circuit to ensure that the equipment can work in harsh environments, longer life, work more stable and reliable, you use more peace of mind. In ensuring sound quality but also playing to improve the efficiency of the machinery, making the product to become the first of many engineering products.
SPE series of five power models to choose from, with a professional input and output interfaces, make more convenient, a variety of operating modes (stereo, bridge) can be used according to the actual situation free to choose.
1. Equipment more secure Excellent convection cooling system.
2. The new line design, greatly improving the efficiency of machinery.
3. Perfect phase response and ultra-wide frequency response.
4. LED indicator clarity, work status at a glance.
5. Professional HI - FI (high fidelity) design, the sound performance of natural.
6. Very high industrial design requirements, reasonable layout, safe and reliable, the whole body simple.
AB main channel operating mode (stereo, bridge), with low cut, input level selection. Bass channel has a high cut, phase, ultra-low frequency adjustment and other functions. When used according to the actual situation free to choose. Multi-function, multi-channel machine design, suitable for a variety of different occasions, voice transmission and PA requirements.
Model | SPE-5000 | SPE-4000 | SPE-3000 |
8Ω Stereo Power | 500W x2 | 400W x2 | 300W x 2 |
4Ω Stereo Power | 720W x2 | 610W x2 | 420W x2 |
8Ω Bridged Stereo Power | 1350W | 1100W | 810W |
Amplifier Case Height | 3U | ||
Frequency Response | 20Hz-25KHz ±0.5% | ||
Signal Noise Ratio(dB) | >96dB | ||
THD+N(rated power,40/KHz)% | <0.05% | ||
Damping Coefficient | >280 | ||
Slew Ratio | 30V/μs | ||
Input Sensitivity | 1Vrms | ||
Input Impedance | Balance 20kΩ/ Unbalance 10KΩ | ||
Input Connectors | 2 x Combo XLR type,3pin | ||
link Connectors | 2 x Male XLR type,3pin | ||
Output Connectors | 2 x NL4 Speakon+4 x Binding post | ||
Output Circuitry | CLASS AB | ||
LED indicator | BLT,Signal,Clip ,Protect | ||
Cooling system | 2PCS intelligent fans for cooking | ||
Protections | power on buffer ,overheating protection ,short circuit protection ,output DC protection | ||
Power supply | AC110V-240V (50Hz-60Hz) | ||
Dimensions(WHD) | 484x132x445mm | ||
Package | 585x205x583mm | ||
N.W. | 16.5kg | 17.4kg | 19.25 |
G.W. | 21.2kg | 22.1kg | 23.9kg |
